Jacketed Coil Condenser

Jacketed Coil Condenser Specification

Features
Corrosion Resistant, Transparent Body, Efficient Heat Exchange, Replaceable Coil

Accuracy
High Condensation Efficiency

Glass Type
Borosilicate Glass

Shape
Cylindrical

Power Supply
Not Required for Standard Use

Control Type
Manual

Temperature Resistance
Up to 250C

Type
Jacketed Coil Condenser

Dimension (L*W*H)
450mm x 125mm x 125mm (approx., customizable)

Equipment Type
Lab Condenser

Equipment Materials
Borosilicate Glass, Stainless Steel

Power
Manual Operation / Not applicable

Material
Borosilicate Glass / Glass 3.3

Application
Laboratory Use, Chemical Processing, Distillations, Cooling Vapors

Capacity (Ltr)
5 to 20 Litres (Customizable)

Number of Coils
Single or Double Coil Available

Jacket Type
Double Walled with Fluid Inlet / Outlet

Mounting
Vertical Mounting

Connections
Standard Ground Joints or Custom Joints

Cooling Fluid
Water or Other Compatible Fluids

Product Code
JCC-1000

Maximum Pressure
Up to 1 bar (Jacket)

Chemical Compatibility
Wide Range for Acidic and Basic Vapors

Jacketed Coil Condenser Trade Information

Minimum Order Quantity
50 Pieces

Supply Ability
1000 Pieces Per Day

Delivery Time
2-5 Days

About Jacketed Coil Condenser

This is characterized by its large cooling surface (cooling coil and outer jacket) and is therefore suitable for condensing vapors from reaction mixtures with low boiling points (distillation).

Superior Chemical Compatibility

Engineered using borosilicate glass, the JCC-1000 Jacketed Coil Condenser offers reliable performance with a broad spectrum of acidic and basic vapors. This material choice ensures resistance against corrosive chemicals, supporting diverse laboratory and chemical processing requirements. The high transparency of the glass also allows for easy monitoring of condensation progress, contributing to operational safety and efficiency.

Efficient Heat Exchange Design

The jacketed, double-walled construction paired with precision coils (single or double) enables optimal cooling using water or other compatible fluids. The condenser maximizes surface area for rapid vapor cooling, promoting high condensation efficiency even under variable workload conditions. Customizable connections and dimensions further enhance integration with existing laboratory setups.

Adaptable for Laboratory Needs

Designed for vertical mounting and available with standard ground or custom joints, this lab condenser suits various systems with ease. Its replaceable coil and manually operated controls make maintenance straightforward, while its power-free operation aligns with sustainable laboratory practices. Customizability in capacity and fittings ensures the right solution for specialized applications.

FAQ's of Jacketed Coil Condenser:

Q: How does the Jacketed Coil Condenser achieve efficient condensation in laboratory applications?

A: The condenser utilizes a double-walled jacket filled with a cooling fluid such as water, circulating around single or double coils. This setup maximizes the surface area for heat exchange, allowing rapid cooling and condensation of vapors, making it highly effective for distillation and chemical processes in the lab.

Q: What types of fluids can be used in the jacket, and how should they be chosen?

A: Water is commonly used as the cooling fluid; however, any fluid compatible with borosilicate glass that remains within the temperature (up to 250C) and pressure (up to 1 bar) limits may be used. Selection depends on the chemical compatibility and efficiency needed for your application.

Q: When is it appropriate to use a single coil versus a double coil configuration?

A: A single coil is suitable for standard condensation tasks with moderate vapor loads. Double coil configurations are preferable when you require enhanced cooling capacity or are condensing larger volumes and more volatile substances, as they provide greater heat transfer surface area.

Q: Where can this condenser be mounted, and does it integrate with standard lab equipment?

A: The JCC-1000 condenser is designed for vertical mounting and is compatible with both standard ground joints and custom connections, allowing easy integration into existing laboratory or processing setups. Customizable dimensions further enable seamless setup with various apparatus.

Q: What is the benefit of a transparent, borosilicate glass body in this condenser?

A: Borosilicate glass is not only highly resistant to thermal shock and chemical corrosion, but its transparency allows for real-time visual monitoring of condensation and fluid flow, reducing risk and ensuring process control.

Q: How is the pressure within the jacket maintained and what are the limits?

A: The condenser's jacket can safely withstand pressures up to 1 bar. It should be used with regulated coolant supply to prevent over-pressurization. Regular maintenance and inspection of seals or joints help maintain safe operating conditions.

Q: What steps should be followed for routine maintenance or replacing the coil?

A: Routine cleaning with suitable laboratory detergents and inspection for any wear is recommended. If coil replacement is necessary, the replaceable design allows for straightforward removal and installation without extensive downtime, supporting ongoing laboratory work.
